Our Huachen American-type integrated PV inverter and step-up transformer system is a fully pre-assembled, grid-ready solution, engineered to convert solar energy into grid-compliant AC power, step up the voltage to 10kV or 35kV, and feed directly into the utility grid. This all-in-one unit drastically simplifies the system architecture and construction workflow of photovoltaic power plants, eliminating complex on-site integration and shortening project delivery timelines. The compact integrated system houses a high-efficiency photovoltaic inverter, busbar bridge, low-voltage compartment (integrated with communication and power distribution functions), oil-immersed transformer (with built-in load switch and fuse protection), and high-voltage cable compartment, all within a unified, rugged enclosure. Every unit is fully assembled, wired, and tested in our ISO-certified factory, delivered as a complete package for rapid on-site installation and commissioning.
By integrating all core PV grid-tie components into a single enclosure, our integrated solar inverter and transformer system eliminates the need for separate equipment layout, complex on-site wiring, and multi-vendor coordination. This cuts on-site construction time by up to 70%, reduces civil engineering costs, and enables faster grid connection and revenue generation for your PV project.
The American-style structure delivers an ultra-compact, space-saving design that minimizes land occupation for your solar farm, making it ideal for both ground-mounted and distributed PV projects. The integrated layout provides easy access to all core components, simplifying routine maintenance and reducing unplanned downtime.
The oil-immersed transformer is equipped with an integrated load switch and fuse set, providing comprehensive overload, short-circuit, and overvoltage protection for the entire system. This design ensures stable, continuous operation even under fluctuating solar irradiance conditions, extending equipment service life and lowering long-term O&M costs.
The unified enclosure is built to withstand harsh outdoor conditions, with excellent anti-corrosion, dust-proof, and weather-resistant performance, eliminating the need for additional protective buildings and reducing overall project investment.
Parameter Category | Parameter Name | Unit | Core Data |
|---|---|---|---|
Basic Electrical Parameters | Rated Grid Voltage | kV | 10, 35 |
Rated Frequency | Hz | 50/60 | |
Switchgear Performance | Rated Current of Built-In Load Switch | A | 630, 1250 |
Rated Short-Time Withstand Current (4×4s) | kA | 20, 25, 31.5 | |
Rated Peak Withstand Current | kA | 50, 63, 80 | |
Rated Short-Circuit Breaking Current | kA | 20, 25, 31.5 | |
Insulation Performance | 1MIN Power Frequency Withstand Voltage | kV | 35, 85 |
Lightning Impulse Withstand Voltage (Peak) | kV | 75, 200 | |
Enclosure Protection | Protection Grade | - | IP54 for Main Enclosure, IP68 for Transformer Tank |
This pre-assembled PV grid-tie inverter transformer integrated system is perfectly suited for:
Utility-scale ground-mounted photovoltaic power plants
Commercial and industrial distributed rooftop PV projects
Agrivoltaic and fishery-solar hybrid PV projects
Remote area off-grid and microgrid solar power systems
Grid-compliant distributed solar generation projects
Ambient operating temperature: -40-+45℃
Altitude: ≤4500m (customized solutions for high-altitude sites)
Maximum outdoor wind speed: ≤35m/s
Pollution Grade: II, III, IV
Seismic Intensity: Grade 8
We provide full end-to-end customization to align with your project’s unique requirements, including tailored inverter power ratings, grid voltage levels, protection configurations, and enclosure upgrades for extreme environmental conditions.
As a leading manufacturer of renewable energy power transmission and distribution equipment, we specialize in delivering turnkey solutions for PV project developers, EPC contractors, and commercial and industrial energy project owners. All our systems undergo rigorous factory testing to ensure full grid compliance before delivery, with dedicated technical support from design to after-sales service. Our in-house engineering team can tailor every aspect of the system to match your project’s specific site and grid requirements, minimizing project risks and maximizing return on investment.
Yes, our standard system supports direct grid connection to both 10kV and 35kV utility networks, with custom voltage options available for specialized project requirements.
Every unit undergoes complete assembly, wiring, and full-load commissioning in our factory, ensuring plug-and-play installation on site with no need for complex on-site testing.
The system includes integrated transformer protection, plus full inverter protection functions, covering overload, short-circuit, overvoltage, under-voltage, and anti-islanding protection to meet strict grid access standards.
For a customized technical solution and detailed quote for your photovoltaic power project, reach out to our expert team today at +86-15852118166 or email us at baojia@hcbyq.com. We will work closely with you to design a solution that meets your project’s grid requirements and performance goals.
